Ponte di misura RLC da 100 Hz a 10 kHz, accuratezza 0,15%.
Test parameter: |Z|, |Y|, C, L, X, B, R, G, D, Q, θ
Test signal frequency: 100 Hz, 120 Hz, 1 kHz, 10 kHz
Basic accuracy: 0.15%
Equivalent circuit: series, parallel
Mathematical function: deviation and percent deviation
Range mode: Auto, Hold, Manual selection
Trigger mode: Internal, Manual, External, BUS
Measurement speed: fast max. 30, medium 10, Slow 3 (times/second) ((≥ 1 kHz))
32-bit core processor
5-digit 4.3-inch TFT LCD display
2 signal source output impedance: 30 Ω, 100 Ω
100 sets memories for internal storage/save
500 memories for U disk storage/save, supports FAT16 and FAT32 files
Save the last parameter settings before power off
Standard interface: RS-232, HANDLER, USB HOST
Dimension: 265 x 100 x 340 mm
Weight: approx. 3.5 kg
