Bandwidth: 200 MHz
Rise time: ≤1.75 ns
Analog channel: 4
Max. sampling rate: 2 GSa/s
Max. memory depth: 220 Mpts
Waveform capture rate (max.): 300.000 wfms/s
Support Test: Charging/Start Circuits, Sensors, Actuators, Ignition, Networks (CAN L/H, CAN FD, LIN, Flexray, K line), Combination Tests
Input sensitivity range: 1 mV/div ~ 10 V/div (1MΩ), 1 mV/div ~ 1 V/div (50Ω)
Bandwith filter: 20 MHz, High Pass / Low Pass (to 30 Hz)
Input impedance: 1 MΩ/50Ω
Timebase range: 1 ns/div ~ 1 ks/div
Trigger types: Edge, Pulse Width, Logic, Nth Edge, Runt, Slope, Time Out, Video
Interfaces: Wi-Fi, USB 3.0/2.0 Host, USB type-C, Grounding, HDMI, Trigger out
Storage: 32 GB
Display: 10.1" LCD capacitive touchdisplay, 1280*800 resolution, 11*10 grids
Battery: 7.4V, 7500mAh Li-Ion battery / 2H duration
Size/Net weight: 265x192x50 mm / 1.9 kg (with battery)
