Impedance: 50 Ω nominal
Power: 100 W
Attenuation: 20 dB
Cooling: air
Input VSWR:
- 1.20 max. from DC to 500 MHz
- 1.25 max. from 500 to 1000 MHz
Output VSWR: 1.25 max. from DC to 1000 MHz
Connectors: N female
Temperature range: from -40° to +45°C
Operating position: any
Maximum attenuation deviation:
- ±0.5 dB (DC – 500 MHz)
- ±0.9 dB (500 – 1000 MHz)
Dimensions: 195 x 70 x 70 mm
Weight: 1.25 kg
